CONSTRUCTION & DIMENSIONS
D
CONDUCTOR PARAMETER
• Number of Conductors
4
• AWG Size
12
• Conductor Stranding
19x25
• Conductor Type
Bare copper
• Nominal DCR
1.7 Ohm/1000ft
• Cabling Lay Length
5.25 in
INSULATION PARAMETER
• Insulation Type
Plenum PVC
• Insulation Thickness
0.012 in
• Insulation Color Code
1.Black,2.Red,3.White,4.Green
SHIELDING PARAMETER
• Shield Type
None
ELECTRICAL CHARACTERISTICS
OVERALL CONSTRUCTION PARAMETERS
Jacket Type
Flexible Plenum
Jacket Thickness
0.015 in
Nominal Cable O.D.
0.308 in
Plenum
Yes
NEC UL Rating
CL2P
RoHS Compliant
Pull Tension
250 lbs
Bend Radius
2.772 in
Cable Weight
104 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
UL Flammability
NFPA 262 Plenum
Operating Range
-0 to 60 Deg C
UL Voltage Rating
300
RELATED PRODUCTS
Non Plenum Number
248
