CONSTRUCTION & DIMENSIONS
-
CONDUCTOR PARAMETER
• Number of Conductors
2
• AWG Size
12
• Conductor Stranding
Stranded
• Conductor Type
Bare Copper
• Nominal DCR
1.8 Ohm/1000ft
• Cabling Lay Length
4.25 in
• Twists/Foot
2.8 twist/ft
INSULATION PARAMETER
• Insulation Type
Thermoplastic
• Insulation Thickness
0.01 in
• Insulation Color Code
1. Black 2.Red
SHIELDING PARAMETER
• Shield Type
None
ELECTRICAL CHARACTERISTICS
• Nom. Cap. Between Conductors
23 pF/ft
OVERALL CONSTRUCTION PARAMETERS
Jacket Type
PVC
Jacket Thickness
0.022 in
Nominal Cable O.D.
0.244 in
Plenum
No
NEC UL Rating
FPLR
RoHS Compliant
Yes
Pull Tension
158 lbs
Bend Radius
2.195 in
Cable Weight
57 lbs
Download Data Sheet
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
UL Flammability
UL1666 Vertical Shaft
Operating Range
-20 to 60 Deg C
UL Voltage Rating
300
