OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
|
-
|
|
Nominal Velocity of Propagation (VP)
|
82 %
|
|
UL Flammability
|
UL1685
|
|
Operating Range
|
-20 to 60 Deg C
|
|
UL Voltage Rating
|
300
|
|
FREQUENCY (MHz)
|
ATTENUATION (db/100ft)
|
|
1 MHz
|
0.24 db/100m
|
|
10 MHz
|
0.52 db/100m
|
|
50 MHz
|
1.18 db/100m
|
|
100 MHz
|
1.83 db/100m
|
|
200 MHz
|
2.73 db/100m
|
|
400 MHz
|
3.95 db/100m
|
|
700 MHz
|
5.38 db/100m
|
|
900 MHz
|
6.13 db/100m
|
|
1000 MHz
|
6.45 db/100m
|
