CONSTRUCTION & DIMENSIONS
CONDUCTOR PARAMETER
• Number of Conductors
2
• AWG Size
20
• Conductor Stranding
7x28
• Conductor Type
Bare copper
• Nominal DCR
10.5 Ohm/1000ft
• Cabling Lay Length
2 in
• Twists/Foot
6 twist/ft
INSULATION PARAMETER
• Insulation Type
Plenum PVC
• Insulation Thickness
0.007 in
• Insulation Color Code
1. Black 2.Red
SHIELDING PARAMETER
• Shield Type
None
ELECTRICAL CHARACTERISTICS
OVERALL CONSTRUCTION PARAMETERS
Jacket Type
Flexible Plenum
Jacket Thickness
0.015 in
Nominal Cable O.D.
0.134 in
Plenum
Yes
NEC UL Rating
CMP
RoHS Compliant
Pull Tension
26 lbs
Bend Radius
1.206 in
Cable Weight
13 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
UL Flammability
NFPA 262 Plenum
Operating Range
-0 to 60 Deg C
UL Voltage Rating
300
