CONDUCTOR PARAMETER
-
• Number of Conductors
• Number of Pairs
1
• AWG Size
22
• Conductor Stranding
7x30
• Conductor Type
Tinned Copper
• Nominal DCR
17 Ohm/1000ft
INSULATION PARAMETER
• Insulation Type
Foam FEP
• Insulation Thickness
0.023 in
• Insulation Color Code
1. Black, 2. White
SHIELDING PARAMETER
• Shield Type
Overall 100% Aluminum Foil
• Drain Wire Type
• Drain Wire AWG
24 AWG
ELECTRICAL CHARACTERISTICS
• Nominal Impedance
120 Ohm
• Nom. Cap. Between Conductors
11.2 pF/ft
Overall Construction
Total Number of Conductors
2 - 1 Pair
Jacket Type
Flexible Plenum
Jacket Thickness
0.015 in
Nominal Cable O.D.
0.177 in
Plenum
Yes
NEC UL Rating
CMP
RoHS Compliant
Pull Tension
36 lbs
Bend Radius
1.44 in
Cable Weight
22 lbs
UL Flammability
NFPA 262 Plenum
Operating Range
-20 to 60 Deg C
UL Voltage Rating
300
