Download Data Sheet
CONSTRUCTION & DIMENSIONS
CONDUCTOR PARAMETER
• Number of Conductors
2
• AWG Size
12
• Conductor Stranding
19x25
• Conductor Type
Bare copper
• Nominal DCR
1.7 Ohm/1000ft
• Cabling Lay Length
4.5 in
• Twists/Foot
2.7 twist/ft
INSULATION PARAMETER
• Insulation Type
PVC
• Insulation Thickness
0.012 in
• Insulation Color Code
1. Black 2.White
SHIELDING PARAMETER
• Shield Type
None
ELECTRICAL CHARACTERISTICS
OVERALL CONSTRUCTION PARAMETERS
Jacket Type
Jacket Thickness
0.017 in
Nominal Cable O.D.
0.264 in
Plenum
No
NEC UL Rating
CL3R, FPLR
RoHS Compliant
Yes
Pull Tension
152 lbs
Bend Radius
2.376 in
Cable Weight
61 lbs
BELDEN: 5000UE
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
UL Flammability
UL1666 Vertical Shaft
Operating Range
-20 to 60 Deg C
UL Voltage Rating
300
RELATED PRODUCTS
Plenum Number
25227B
Aquaseal Direct Burial Number
AQ227
SpeakOn Panel Mount
CN-NL4MP
