CONSTRUCTION & DIMENSIONS
CONDUCTOR PARAMETER
• Number of Conductors
4
• AWG Size
14
• Conductor Stranding
19x27
• Conductor Type
Bare copper
• Nominal DCR
2.7 Ohm/1000ft
• Cabling Lay Length
4.75 in
INSULATION PARAMETER
• Insulation Type
PVC
• Insulation Thickness
0.012 in
• Insulation Color Code
1.Black,2.Red,3.White,4.Green
SHIELDING PARAMETER
• Shield Type
None
ELECTRICAL CHARACTERISTICS
OVERALL CONSTRUCTION PARAMETERS
Jacket Type
Jacket Thickness
0.017 in
Nominal Cable O.D.
0.278 in
Plenum
No
NEC UL Rating
CL3R, FPLR
RoHS Compliant
Yes
Pull Tension
190 lbs
Bend Radius
2.502 in
Cable Weight
79 lbs
BELDEN: 5102UE
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
UL Flammability
UL1666 Vertical Shaft
Operating Range
-20 to 60 Deg C
UL Voltage Rating
300
RELATED PRODUCTS
Plenum Number
25246B
Aquaseal Direct Burial Number
AQ246
4 Pole SpeakOn
CN-NL4FC
SpeakOn Panel Mount
CN-NL4MP
