CONSTRUCTION & DIMENSIONS
CONDUCTOR PARAMETER
• Number of Conductors
4
• AWG Size
16
• Conductor Stranding
19x29
• Conductor Type
Bare copper
• Nominal DCR
4.2 Ohm/1000ft
• Cabling Lay Length
3 in
INSULATION PARAMETER
• Insulation Type
Plenum PVC
• Insulation Thickness
0.008 in
• Insulation Color Code
1.Black,2.Red,3.White,4.Green
SHIELDING PARAMETER
• Shield Type
None
ELECTRICAL CHARACTERISTICS
OVERALL CONSTRUCTION PARAMETERS
Jacket Type
Flexible Plenum
Jacket Thickness
0.015 in
Nominal Cable O.D.
0.208 in
Plenum
Yes
NEC UL Rating
CMP
RoHS Compliant
Pull Tension
92 lbs
Bend Radius
1.871 in
Cable Weight
44 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
UL Flammability
NFPA 262 Plenum
Operating Range
-0 to 60 Deg C
UL Voltage Rating
300
