OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
|
-
|
|
Nominal Velocity of Propagation (VP)
|
82 %
|
|
UL Flammability
|
NFPA 262 Plenum
|
|
Operating Range
|
-0 to 60 Deg C
|
|
UL Voltage Rating
|
300
|
|
FREQUENCY (MHz)
|
ATTENUATION (db/100ft)
|
|
5 MHz
|
0.45 dB
|
|
55 MHz
|
1.6 dB
|
|
100 MHz
|
2 dB
|
|
270 MHz
|
2.9 dB
|
|
400 MHz
|
4.5 dB
|
|
540 MHz
|
4.9 dB
|
|
750 MHz
|
6.6 dB
|
|
1000 MHz
|
8 dB
|
|
1450 MHz
|
10.3 dB
|
|
2250 MHz
|
13.36 dB
|
|
3000 MHz
|
15.42 dB
|
