CONSTRUCTION & DIMENSIONS
-
CONDUCTOR PARAMETER
• Number of Pairs
4
• AWG Size
18
• Conductor Stranding
7x26
• Conductor Type
Bare copper
• Nominal DCR
6.2 Ohm/1000ft
INSULATION PARAMETER
• Insulation Type
Plenum PVC
• Insulation Thickness
0.008 in
• Insulation Color Code
1. Black, Red, 2.Black, White 3.Black, Green 4. Black, Blue
SHIELDING PARAMETER
• Shield Type
None
ELECTRICAL CHARACTERISTICS
OVERALL CONSTRUCTION PARAMETERS
Jacket Type
Flexible Plenum
Jacket Thickness
0.015 in
Nominal Cable O.D.
0.304 in
Plenum
Yes
NEC UL Rating
CMP
RoHS Compliant
Bend Radius
2.736 in
Cable Weight
58 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
UL Flammability
NFPA 262 Plenum
Operating Range
-0 to 60 Deg C
UL Voltage Rating
300
RELATED PRODUCTS
Non Plenum Number
753
