CONSTRUCTION & DIMENSIONS
-
CONDUCTOR PARAMETER
• Number of Conductors
4
• AWG Size
16
• Conductor Stranding
Solid
• Conductor Type
Bare Copper
• Nominal DCR
4.1 Ohm/1000ft
INSULATION PARAMETER
• Insulation Type
Polypropylene - PP
• Insulation Thickness
0.008 in
• Insulation Color Code
1.Black,2.Red,3.Brown,4.Blue
SHIELDING PARAMETER
• Shield Type
Overall 100% Aluminum Foil
• Drain Wire Type
Tinned Copper
• Drain Wire AWG
24 AWG
ELECTRICAL CHARACTERISTICS
• Nom. Cap. Between Conductors
43 pF/ft
• Nom. Cap. Conductor to Shield
78 pF/ft
OVERALL CONSTRUCTION PARAMETERS
Jacket Type
PVC
Jacket Thickness
0.017 in
Nominal Cable O.D.
0.2 in
Plenum
No
NEC UL Rating
FPLR
RoHS Compliant
Yes
Pull Tension
128 lbs
Bend Radius
1.8 in
Cable Weight
50 lbs
Download Data Sheet
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
UL Flammability
UL1666 Vertical Shaft
Operating Range
-20 to 75 Deg C
UL Voltage Rating
300
RELATED PRODUCTS
Plenum Number
603164B
Aquaseal Direct Burial Number
AQ3245
