Download Specification
Component
Card Reader
Door Contact
Request To Exit
Lock Power
CONDUCTOR PARAMETER
-
Number of Conductors
2
4
Number of Pairs
3
AWG Size
22
18
Conductor Stranding
7x30
7x26
Conductor Type
Bare Copper
Nominal DCR
17 Ohm/1000ft
6.2 Ohm/1000ft
INSULATION PARAMETER
Insulation Type
Plenum PVC
Insulation Thickness
0.009 in
0.010 in
Insulation Color Code
1. Black,Red 2.White,Green 3.Brown, Blue
1. Black 2.Red
1.Black,2.Red,3.White,4.Green
SHIELDING PARAMETER
Shield Type
Overall 100% Aluminum Foil
Drain Wire Type
Tinned Copper
Drain Wire AWG
24 AWG
ELECTRICAL CHARACTERISTICS
Nom. Cap. Between Conductors
34 pF/ft
54 pF/ft
Nom. Cap. Conductor to Shield
67 pF/ft
97 pF/ft
INNER JACKET COLOR
Orange
White
Blue
Gray
OVERALL CONSTRUCTION PARAMETERS
Total Number of Conductors
16
Jacket Type
Flexible Plenum
Nominal Cable O.D.
0.485 in
Plenum
Yes
NEC UL Rating
CMP
RoHS Compliant
Bend Radius
4.85 in
Cable Weight
106 lbs
Belden: 658AFJ
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
UL Flammability
NFPA 262 Plenum
Operating Range
-0 to 60 Deg C
UL Voltage Rating
300
