OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS
|
-
|
|
Nominal Velocity of Propagation (VP)
|
82 %
|
|
UL Flammability
|
NFPA 262 Plenum
|
|
Operating Range
|
-0 to 60 Deg C
|
|
UL Voltage Rating
|
300
|
|
FREQUENCY (MHz)
|
ATTENUATION (db/100ft)
|
|
1 MHz
|
0.48 dB
|
|
3.6 MHz
|
0.99 dB
|
|
10 MHz
|
1.75 dB
|
|
71.5 MHz
|
3.54 dB
|
|
135 MHz
|
4.73 dB
|
|
270 MHz
|
6.57 dB
|
|
360 MHz
|
7.79 dB
|
|
540 MHz
|
9.38 dB
|
|
720 MHz
|
10.98 dB
|
|
1000 MHz
|
13.46 dB
|
|
2250 MHz
|
19.28 dB
|
|
3000 MHz
|
22.8 dB
|
